BURLINGTON F112 EVAL Radiation Protection Coat Apron

Full Lead Protection and Enhanced Comfort for Extended Procedures

The BURLINGTON F112 EVAL radiation protection coat apron has been designed to provide maximum protection against ionizing radiation during medium to long-duration procedures. Thanks to its full-overlap design and 100% lead-based protective material, it ensures optimal coverage of both the front and back of the body throughout the procedure.

Its ergonomic design helps reduce the perceived weight of the apron while maintaining excellent wearing comfort. Equipped with a wide 15 cm adjustable elastic belt, adjustable lumbar support, and padded shoulders, the F112 EVAL promotes balanced weight distribution between the shoulders and hips, helping to minimise fatigue during extended procedures.

EVAL Material: Certified Protection up to 150 kV

Manufactured from BURLINGTON EVAL lead-based protective material, the F112 provides consistent lead equivalency across all imaging energies, including high-energy applications.

- Available lead equivalencies: 0.35/0.25 mm Pb or 0.50/0.25 mm Pb
- Tested and approved from 50 kV to 150 kV in accordance with IEC 61331-1:2014
- Suitable for procedures using X-ray energies above 125 kV
- Lead equivalency determined using the inverse broad beam geometry method in accordance with IEC 61331-1:2014
- 100% lead-based protective material for consistent radiation attenuation

Recommended Applications

The F112 EVAL coat apron is particularly suitable for professionals working in:

- Interventional Radiology
- Interventional Cardiology
- CT Imaging
- General Radiography
- Mammography
- Dental Imaging
- Computed Tomography
- Nuclear Medicine

It is especially recommended for procedures lasting more than 30 minutes that require enhanced radiation protection and maximum comfort.

Technical Features

- Full-overlap design for maximum protection
- Full-height front Velcro closure
- 15 cm adjustable elastic belt
- Optimised weight distribution between shoulders and hips
- Adjustable lumbar support
- Thick padded shoulders for enhanced comfort
- Standard chest pocket
- Quick and easy donning and removal

Compliance and Certification

- Compliant with IEC 61331-3:2014
- HC Category (Heavy Closed Use)
- CE Certified 89/686/EEC
- Personal Protective Equipment (PPE) Category III
- Tested and approved in accordance with NF EN 61331-3:2014

BURLINGTON EVAL Material

EVAL material provides a high level of radiation protection while ensuring excellent durability.

- 3.62 kg/m2 at 0.25 mm Pb equivalency
- 4.9 kg/m2 at 0.35 mm Pb equivalency
- 7.11 kg/m2 at 0.50 mm Pb equivalency
- 98% recyclable material
- Manufactured using a hot reformulation process

30 Colours Available

- Antibacterial outer coverings
- 4 patterned PVC colours
- 12 Polyurethane (PU) colours, plain or patterned
- 14 Nylon colours, plain or patterned
- Durable and easy-to-clean surfaces

Key Benefits of the BURLINGTON F112 EVAL Coat Apron

- Certified lead protection up to 150 kV
- Full-overlap design for maximum coverage
- 100% lead-based material for consistent protection
- Weight distribution between shoulders and hips
- Adjustable lumbar support for long-lasting comfort
- Ideal for procedures lasting more than 30 minutes
- Compliant with IEC 61331-1 and IEC 61331-3 standards
- 98% recyclable material
- 5 year warranty
